| Pharmaceutical Machines » Capsule Section |
|
|
| |
|
| |
|
| |
|
| |
| Soft gelatin machine is very much similar to water cooling machine especially designed and manufactured as per latest market trends and using most advance tools and technologies. The major features of product include remarkable finishing, exact filling, excellent productivity, and maximum stability. It is generally necessary to manufacture capsules of different sizes and soft in texture. The application areas include cosmetic industries, health industries and medicines. |
| |
|
| |
|
| |
|
| |
| FEATURES |
 |
The product has advance cooling system to reduce dust contamination. |
|
Advance driving system to inject medicines properly. |
|
Advance elevator system and wonderful tight model inside injecting part. |
|
FDA approved conveyor belt assuring precise and smooth operations. |
|
Food grade belt is highly non-toxic, east to wash and non-sticky too. |
|
Rotary cage has prepared using stainless steel material having no dead edges and highly durable too. |
|
Only branded electronic components embedded for stable performance. |
|
All the electric parts adopt well-known brand in the world, the performance is stable. |
|
| |
| Model : |
SG2-200 |
SG2-250 |
SG2-300 |
SG0.8-110A |
| Roller Dir Rated Speed : |
0-7r/min |
0-5r/min |
0-5r/min |
0-3.5r/min |
| Roller Dir Size : |
Ø103 * 200mm |
Ø150 * 250mm |
Ø150 * 300 |
Ø72 * 110 |
| Single Piston Feeding Volume : |
0-2ml |
0-2ml |
0-2ml |
0-0.8ml |
| Power Supply : |
380v 50Hz 9.5kw 220v 2kw |
380v 50Hz 12.8kw 220v 2.6kw |
380v 50Hz 12.8kw 220v 2.9kw |
380v 50Hz 0.75kw 220v 0.75kw |
| Noise : |
<75dBA |
<75dBA |
<75dBA |
<75dBA |
| Dimension : |
1820 * 980 * 1820 |
2060 * 1100 * 2000 |
2060 *1150 * 2000 |
850 * 750 * 1520 |
| Net Weight : |
1000kg |
1700kg |
1800kg |
400kg |
|
| |
| Output : |
| 23,000 upto 45,000 soft gelatin capsules per hour, varied output. |
|
| |
|
|
|
|
|
|
|
